CSD87334Q3D

CSD87334Q3D Overview

This product is manufactured by Texas Instruments. The product can operate at a maximum temperature of SMD/SMT. VSON-8 package/case type is utilized by this product. This product is equipped with 1 Channel for efficient performance. Vds rating of 30 V 20 A continuous drain current Rds On value of 8.3 mOhms, 8.3 mOhms Gate-Source Threshold Voltage Range: 750 mV Gate-Source Voltage: 8 V The minimum operating temperature of this product is - 55 C. The product can operate at a maximum temperature of + 150 C. 6 W This product has a Single configuration. The Channel Mode is set to Enhancement. The product's NexFET is Blue Gecko. Reel packaging for easy dispensing The height of the product is 1 mm. 3.3 mm long The Transistor Type is 1 N-channel. Texas Instruments is a trusted brand for quality electronics 17 ns, 17 ns fall time MOSFET product type Rise Time is 7 ns, 7 ns. 2500 of 100 MOSFETs as subcategory Turn-off delay time is 11 ns, 11 ns. The typical turn-on delay time is 4 ns, 4 ns. 1. 0.002677 oz of Unit Weight

CSD87334Q3D Image

CSD87334Q3D Specifications

• Manufacturer: Texas Instruments
• Product Category: MOSFET
• RoHS: Y
• Technology: Si
• Mounting Style: SMD/SMT
• Package / Case: VSON-8
• Number of Channels: 1 Channel
• Transistor Polarity: N-Channel
• Vds - Drain-Source Breakdown Voltage: 30 V
• Id - Continuous Drain Current: 20 A
• Rds On - Drain-Source Resistance: 8.3 mOhms, 8.3 mOhms
• Vgs th - Gate-Source Threshold Voltage: 750 mV
• Vgs - Gate-Source Voltage: 8 V
• Qg - Gate Charge: 8.3 nC, 8.3 nC
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 150 C
• Pd - Power Dissipation: 6 W
• Configuration: Single
• Channel Mode: Enhancement
• Tradename: NexFET
• Packaging: Reel
• Height: 1 mm
• Length: 3.3 mm
• Series: CSD87334Q3D
• Transistor Type: 1 N-channel
• Width: 3.3 mm
• Brand: Texas Instruments
• Fall Time: 17 ns, 17 ns
• Product Type: MOSFET
• Rise Time: 7 ns, 7 ns
• Factory Pack Quantity: 2500
• Subcategory: MOSFETs
• Typical Turn-Off Delay Time: 11 ns, 11 ns
• Typical Turn-On Delay Time: 4 ns, 4 ns
• Unit Weight: 0.002677 oz
