UCD7138DRST

UCD7138DRST Overview

This product is manufactured by Texas Instruments. MOSFET Gate Drivers This device belongs to the Low Side type. The product can operate at a maximum temperature of SMD/SMT. WSON-6 package/case type is utilized by this product. 1 Output is the number of outputs provided by this product. Rise Time is 4 ns. 3.5 ns fall time Supply Voltage - Min: 4.5 V Supply Voltage - Max: 18 V The minimum operating temperature of this product is - 40 C. The product can operate at a maximum temperature of + 125 C. Reel packaging for easy dispensing Texas Instruments is a trusted brand for quality electronics This product does not have a No Shutdown feature, ensuring continuous operation. 22.9 ns maximum turn-off delay time The 26.6 ns. Yes regarding Moisture Sensitivity Gate Drivers product type 250 of 100 PMIC - Power Management ICs as subcategory 1. 0.000342 oz of Unit Weight

UCD7138DRST Image

UCD7138DRST Specifications

• Manufacturer: Texas Instruments
• Product Category: Gate Drivers
• RoHS: Y
• Product: MOSFET Gate Drivers
• Type: Low Side
• Mounting Style: SMD/SMT
• Package / Case: WSON-6
• Number of Drivers: 1 Driver
• Number of Outputs: 1 Output
• Rise Time: 4 ns
• Fall Time: 3.5 ns
• Supply Voltage - Min: 4.5 V
• Supply Voltage - Max: 18 V
• Operating Supply Current: 13 mA
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Series: UCD7138
• Packaging: Reel
• Operating Temperature Range: - 40 C to + 125 C
• Technology: Si
• Brand: Texas Instruments
• Shutdown: No Shutdown
• Maximum Turn-Off Delay Time: 22.9 ns
• Maximum Turn-On Delay Time: 26.6 ns
• Moisture Sensitive: Yes
• Product Type: Gate Drivers
• Factory Pack Quantity: 250
• Subcategory: PMIC - Power Management ICs
• Unit Weight: 0.000342 oz
