CSD13381F4

CSD13381F4 Overview

Product belongs to the NexFET series. Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style Trade name: NexFET. 3-XFDFN Si is the technology used. Operational temperature range: -55°C ~ 150°C (TJ) Surface Mount mounting type Number of channels: 1 Channel Supplier device package: 3-PICOSTAR Configuration Single This product uses an MOSFET N-Channel, Metal Oxide FET-Type transistor. Transistor type: 1 N-Channel 12V This product has an 200pF @ 6V value of 300pF @ 25V. This product's Standard. 2.1A (Ta) continuous drain-ID current at 25°C; This product has an 180 mOhm @ 500mA, 4.5V of 12 Ohm @ 150mA, 0V. Power-off control: 500 mW Maximum operating temperature of + 150 C Minimum operating temperature: - 55 C This product has a 3.8 ns of 16 ns. This product has a 1.5 ns of 16 ns. This product's 8 V. The ID of continuous drain current is 7 A. This product has a Vds-Drain-Source-Breakdown-Voltageof 12 V. This product has a 850 mV Vgs-th gate-source threshold voltage for efficient power management. The 180 mOhms for this product is 12 Ohms. The transistor polarity is N-Channel. 'Typical-Turn-Off-Delay-Time' of 11 ns This product has a 3.7 ns. Qg-Gate-Charge is 1.06 nC.

CSD13381F4 Image

CSD13381F4 Specifications

• Manufacturer Texas Instruments
• Product Category FETs - Single
• Series NexFET
• Packaging Digi-ReelR Alternate Packaging
• Mounting-Style SMD/SMT
• Tradename NexFET
• Package-Case 3-XFDFN
• Technology Si
• Operating-Temperature -55°C ~ 150°C (TJ)
• Mounting-Type Surface Mount
• Number-of-Channels 1 Channel
• Supplier-Device-Package 3-PICOSTAR
• Configuration Single
• FET-Type MOSFET N-Channel, Metal Oxide
• Power-Max 500mW
• Transistor-Type 1 N-Channel
• Drain-to-Source-Voltage-Vdss 12V
• Input-Capacitance-Ciss-Vds 200pF @ 6V
• FET-Feature Standard
• Current-Continuous-Drain-Id-25°C 2.1A (Ta)
• Rds-On-Max-Id-Vgs 180 mOhm @ 500mA, 4.5V
• Vgs-th-Max-Id 1.1V @ 250μA
• Gate-Charge-Qg-Vgs 1.4nC @ 4.5V
• Pd-Power-Dissipation 500 mW
• Maximum-Operating-Temperature + 150 C
• Minimum-Operating-Temperature - 55 C
• Fall-Time 3.8 ns
• Rise-Time 1.5 ns
• Vgs-Gate-Source-Voltage 8 V
• Id-Continuous-Drain-Current 7 A
• Vds-Drain-Source-Breakdown-Voltage 12 V
• Vgs-th-Gate-Source-Threshold-Voltage 850 mV
• Rds-On-Drain-Source-Resistance 180 mOhms
• Transistor-Polarity N-Channel
• Typical-Turn-Off-Delay-Time 11 ns
• Typical-Turn-On-Delay-Time 3.7 ns
• Qg-Gate-Charge 1.06 nC
