LE45CD-TR

LE45CD-TR Overview

Product belongs to the LE45C series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.017870 oz SMD/SMT Mounting-Style SO-8 Operational temperature range: -40°C ~ 125°C Surface Mount mounting type Output-Type: Fixed Supplier device package: 8-SO Up to 18V voltage input Number-of-Outputs: 1 Output Output voltage: 4.5V Positive Fixed regulator topology The product has 1 of 1. Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Output voltage: 4.5 V Maximum Input Voltage: 18 V Output current: 100 mA Load regulation is 25 mV. The voltage regulation accuracy of this product is 2 %. Input bias current of 1.5 mA This product has a 3 mA of 7 mA, making it ideal for low-power applications. The 0.2 V at 100 mA. The maximum 500 mV is 360 mV. This product's 30 mV is 0.01 %/V.

LE45CD-TR Image

LE45CD-TR Specifications

• Manufacturer STMicroelectronics
• Product Category PMIC - Voltage Regulators - Linear
• Series LE45C
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.017870 oz
• Mounting-Style SMD/SMT
• Package-Case SO-8
• Operating-Temperature -40°C ~ 125°C
• Mounting-Type Surface Mount
• Output-Type Fixed
• Supplier-Device-Package 8-SO
• Voltage-Input Up to 18V
• Number-of-Outputs 1 Output
• Current-Output 100mA
• Voltage-Output 4.5V
• Regulator-Topology Positive Fixed
• Voltage-Dropout-Typical 0.2V @ 100mA
• Number-of-Regulators 1
• Current-Limit-Min 150mA
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Output-Voltage 4.5 V
• Input-Voltage-MAX 18 V
• Output-Current 100 mA
• Load-Regulation 25 mV
• Voltage-Regulation-Accuracy 2 %
• Ib-Input-Bias-Current 1.5 mA
• Quiescent-Current 3 mA
• Dropout-Voltage 0.2 V at 100 mA
• Dropout-Voltage-Max 500 mV
• Line-Regulation 30 mV
