| Mfr. #: | LED2001PUR |
|---|---|
| メーカー: | STMicroelectronics |
| 説明: | LED Lighting Drivers 4A 850kHz Step-Down 3.0V to 18V 100mV |
| ライフサイクル: | メーカー新製品 |
| データシート: | LED2001PUR データシート |
Product belongs to the LED2001 series. Type: DC DC Regulator Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style VFQFPN-8 This product's 850kHz range is 0Hz to 2.2GHz. Operational temperature range: -40°C ~ 150°C (TJ) Surface Mount mounting type Versatile Lighting, Signage applications for maximum usability Supplier device package: 8-VFQFPN (4x4) Number-of-Outputs: 1 Current-Output-Channel is 4A This product has Yes. Topology: Step-Down (Buck) feedback The maximum voltage supply is 18V. The minimum 3V required for voltage supply. Output voltage: - Dimming control is done through PWM communication. Power-off control: 2 W Maximum operating temperature of + 150 C Minimum operating temperature: - 40 C The operating frequency is 850 kHz. Input Voltage Range: 3 V to 18 V Output current: 4 A Maximum supply current: 2.5 mA
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
LED2001PUR Specifications
