LM2698EVAL

LM2698EVAL Overview

Product belongs to the SIMPLE SWITCHERR series. This product is categorized as Evaluation Boards Type: Voltage Regulators - Switching Regulators Trade name: Simple Switcher. The DC/DC, Step Up is the Main-Purpose. 4.5 V ~ 9 V voltage input This product features 'Frequency-Switching' at - for optimal performance. Output voltage: 12V Boost regulator topology - Included item: Board. IC package type: LM2698 Board type: Fully Populated. The product has 1, Non-Isolated outputs. Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Output voltage: 12 V This product is an SIMPLE SWITCHER 1.35 A Boost Regulator. This tool is designed for the LM2698. Our product measures 1.75 in x 1.65 in in dimensions for compact and convenient use. Input Voltage Range: 4.5 V to 9 V Output current: 400 mA

LM2698EVAL Image

LM2698EVAL Specifications

• Manufacturer Texas Instruments
• Product Category Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
• Series SIMPLE SWITCHERR
• Product Evaluation Boards
• Type Voltage Regulators - Switching Regulators
• Tradename Simple Switcher
• Main-Purpose DC/DC, Step Up
• Voltage-Input 4.5 V ~ 9 V
• Frequency-Switching -
• Current-Output 400mA
• Voltage-Output 12V
• Regulator-Topology Boost
• Power-Output -
• Supplied-Contents Board
• Utilized-IC-Part LM2698
• Board-Type Fully Populated
• Outputs-and-Type 1, Non-Isolated
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Output-Voltage 12 V
• Description-Function SIMPLE SWITCHER 1.35 A Boost Regulator
• Tool-Is-For-Evaluation-Of LM2698
• Dimensions 1.75 in x 1.65 in
• Input-Voltage 4.5 V to 9 V
• Output-Current 400 mA
