OPA2684ID Overview

Product belongs to the OPA2684 series. This product is categorized as Operational Amplifiers Tube is the packaging method for this product Weight of 0.002677 oz SMD/SMT Mounting-Style Number of channels: 2 Channel Topology: Current Feedback feedback The amplifier is of Current Feedback type. Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C 3.6 mA is 92 nA. Maximum supply voltage of 12 V Minimum supply voltage is 5 V SOIC-8 Input bias current of 11 uA The 3.8 mV. The 58 dB. The CMRR-Common-Mode-Rejection-Ratio is 52 dB. The 3.7 nV/sqrt Hz of this product is 110 nV/sqrt Hz.

OPA2684ID Image

OPA2684ID Specifications

• Manufacturer TI
• Product Category Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
• Series OPA2684
• Product Operational Amplifiers
• Packaging Tube
• Unit-Weight 0.002677 oz
• Mounting-Style SMD/SMT
• Number-of-Channels 2 Channel
• Topology Current Feedback
• Amplifier-Type Current Feedback
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Current 3.6 mA
• Supply-Voltage-Max 12 V
• Supply-Voltage-Min 5 V
• Package-Case SOIC-8
• Ib-Input-Bias-Current 11 uA
• Vos-Input-Offset-Voltage 3.8 mV
• PSRR-Power-Supply-Rejection-Ratio 58 dB
• CMRR-Common-Mode-Rejection-Ratio 52 dB
• GBP-Gain-Bandwidth-Product 140 MHz
• SR-Slew-Rate 380 V/us
• en-Input-Voltage-Noise-Density 3.7 nV/sqrt Hz
