STH270N4F3-2

STH270N4F3-2 Overview

Product belongs to the N-channel STripFET series. Reel is the packaging method for this product Weight of 0.139332 oz SMD/SMT Mounting-Style Trade name: STripFET. TO-252-3 Si is the technology used. Number of channels: 1 Channel Configuration Single Transistor type: 1 N-Channel Power-off control: 300 W Maximum operating temperature of + 175 C Minimum operating temperature: - 55 C This product has a 45 ns of 16 ns. This product has a 180 ns of 16 ns. This product's 20 V. The ID of continuous drain current is 180 A. This product has a Vds-Drain-Source-Breakdown-Voltageof 40 V. This product has a 2 V Vgs-th gate-source threshold voltage for efficient power management. The 1.4 mOhms for this product is 12 Ohms. The transistor polarity is N-Channel. 'Typical-Turn-Off-Delay-Time' of 110 ns This product has a 25 ns. Qg-Gate-Charge is 110 nC. This product operates in Enhancement channel mode for optimal performance.

STH270N4F3-2 Image

STH270N4F3-2 Specifications

• Manufacturer STMicroelectronics
• Product Category Transistors - FETs, MOSFETs - Single
• Series N-channel STripFET
• Packaging Reel
• Unit-Weight 0.139332 oz
• Mounting-Style SMD/SMT
• Tradename STripFET
• Package-Case TO-252-3
• Technology Si
• Number-of-Channels 1 Channel
• Configuration Single
• Transistor-Type 1 N-Channel
• Pd-Power-Dissipation 300 W
• Maximum-Operating-Temperature + 175 C
• Minimum-Operating-Temperature - 55 C
• Fall-Time 45 ns
• Rise-Time 180 ns
• Vgs-Gate-Source-Voltage 20 V
• Id-Continuous-Drain-Current 180 A
• Vds-Drain-Source-Breakdown-Voltage 40 V
• Vgs-th-Gate-Source-Threshold-Voltage 2 V
• Rds-On-Drain-Source-Resistance 1.4 mOhms
• Transistor-Polarity N-Channel
• Typical-Turn-Off-Delay-Time 110 ns
• Typical-Turn-On-Delay-Time 25 ns
• Qg-Gate-Charge 110 nC
• Channel-Mode Enhancement
