| Mfr. #: | STPS1045B |
|---|---|
| メーカー: | STMicroelectronics |
| 説明: | DIODE SCHOTTKY 45V 10A DPAK |
| ライフサイクル: | メーカー新製品 |
| データシート: | STPS1045B データシート |
Product belongs to the STPS1045B series. This product is categorized as Schottky Rectifiers Tube is the packaging method for this product Weight of 0.009185 oz SMD/SMT Mounting-Style TO-252-3, DPak (2 Leads + Tab), SC-63 Si is the technology used. Surface Mount mounting type Supplier device package: D-Pak Configuration Single Dual Anode Operating frequency: Fast Recovery = 200mA (Io) Schottky diode type The 200μA @ 45V Current-Reverse-Leakage-Vr 1. Vf Max 630mV @ 10A is the Voltage-Forward; Maximum DC reverse voltage 45V The 10A Current-Average-Rectified-Io; The capacitance value of this product is 760pF @ 5V, 1MHz for maximum efficiency. Operating-Temperature-Junction: -40°C ~ 175°C Maximum operating temperature of + 175 C Minimum operating temperature: - 65 C Vf-Forward-Voltage: 0.84 V at 20 A Ir-Reverse-Current is 100 uA. If-Forward-Current is 10 A. VRRM (45 V) Reverse Voltage 75 A IFSM Forward Surge Current
