| Mfr. #: | TPS61199PWP |
|---|---|
| メーカー: | Texas Instruments |
| 説明: | LED Lighting Drivers White LED Drive |
| ライフサイクル: | メーカー新製品 |
| データシート: | TPS61199PWP データシート |
Product belongs to the TPS61199 series. Type: DC DC Controller Tube Alternate Packaging is the packaging method for this product Weight of 0.002885 oz SMD/SMT Mounting-Style HTSSOP-20 This product's 500kHz ~ 800kHz range is 0Hz to 2.2GHz. Operational temperature range: -40°C ~ 85°C (TA) Surface Mount mounting type Output-Type: Current Mode Versatile Backlight applications for maximum usability Supplier device package: 20-HTSSOP Number-of-Outputs: 8 Current-Output-Channel is 70mA This product has No. Topology: Step-Up (Boost) feedback The maximum voltage supply is 30V. The minimum 8V required for voltage supply. Output voltage: - Dimming control is done through PWM communication. Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C The operating frequency is 300 kHz to 800 kHz. Input Voltage Range: 8 V to 30 V Output current: 70 mA Maximum supply current: 1.5 mA
