TXB0304RSVR

TXB0304RSVR Overview

Product belongs to the TXB0304 series. Type: Bidirectional Voltage Level Translators Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.001443 oz SMD/SMT Mounting-Style UQFN-16 Operational temperature range: -40°C ~ 85°C (TA) Surface Mount mounting type Output-Type: Tri-State, Non-Inverted Supplier device package: 16-UQFN (2.6x1.8) 1 is 8. Non-inverting logic type This product uses Voltage Level as the translator type This product's Bidirectional 4 Channels The product is designed to operate at 0.9 V ~ 3.6 V. The Voltage-VCCB is set at 0.9 V ~ 3.6 V. Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C 5 uA is 92 nA. The TXB0304EVM. Maximum supply voltage of 3.6 V Minimum supply voltage is 0.9 V TXB0304 logic type 3.7 ns to 18.9 ns is 23 microseconds.

TXB0304RSVR Image

TXB0304RSVR Specifications

• Manufacturer Texas Instruments
• Product Category Logic - Translators, Level Shifters
• Series TXB0304
• Type Bidirectional Voltage Level Translators
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.001443 oz
• Mounting-Style SMD/SMT
• Package-Case UQFN-16
• Operating-Temperature -40°C ~ 85°C (TA)
• Mounting-Type Surface Mount
• Output-Type Tri-State, Non-Inverted
• Features Auto-Direction Sensing
• Supplier-Device-Package 16-UQFN (2.6x1.8)
• Number-of-Circuits 1
• Data-Rate 100Mbps
• Logic-Type Non-inverting
• Translator-Type Voltage Level
• Channel-Type Bidirectional
• Channels-per-Circuit 4
• Voltage-VCCA 0.9 V ~ 3.6 V
• Voltage-VCCB 0.9 V ~ 3.6 V
• Input-Signal -
• Output-Signal -
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Current 5 uA
• Development-Kit TXB0304EVM
• Supply-Voltage-Max 3.6 V
• Supply-Voltage-Min 0.9 V
• Logic-Family TXB0304
• Propagation-Delay-Time 3.7 ns to 18.9 ns
