VNN3NV04PTR-E

VNN3NV04PTR-E Overview

Product belongs to the OMNIFET II, VIPower series. This product is categorized as MOSFET Gate Drivers Type: Low-Side Non Inverting Driver Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.006632 oz SMD/SMT Mounting-Style SOT-223 The Non-Inverting for this product is CMOS/TTL. Operational temperature range: -40°C ~ 150°C (TJ) Output-Type: N-Channel Interface: On/Off Supplier device package: SOT-223 The Ratio-Input:Output for this product is 1899/12/30 1:01:00. Configuration Low-Side Number-of-Outputs: 1 Supply Voltage: Not Required The Low Side. The 120 mOhm (Max). Voltage-Load range is 36V (Max). Our product delivers a 3.5A of 50mA for efficient power management. The Switch-Type is General Purpose. Power-off control: 35 W Maximum operating temperature of + 150 C Minimum operating temperature: - 40 C 100 uA is 92 nA. Output current: 3.5 A This product has a 250 ns of 16 ns. This product has a 250 ns of 16 ns. Maximum supply voltage of 55 V Minimum supply voltage is 2.5 V Number-of-Drivers: 1 Driver This product has a Maximum-Turn-Off-Delay-Time of 450 ns (Typ). 90 ns (Typ) maximum turn-on delay time

VNN3NV04PTR-E Image

VNN3NV04PTR-E Specifications

• Manufacturer ST
• Product Category PMIC - Power Distribution Switches, Load Drivers
• Series OMNIFET II, VIPower
• Product MOSFET Gate Drivers
• Type Low-Side Non Inverting Driver
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.006632 oz
• Mounting-Style SMD/SMT
• Package-Case SOT-223
• Input-Type Non-Inverting
• Operating-Temperature -40°C ~ 150°C (TJ)
• Output-Type N-Channel
• Features -
• Interface On/Off
• Supplier-Device-Package SOT-223
• Ratio-Input:Output 1899/12/30 1:01:00
• Configuration Low-Side
• Number-of-Outputs 1
• Voltage-Supply-Vcc-Vdd Not Required
• Fault-Protection Current Limiting (Fixed), Over Temperature, Over Voltage
• Output-Configuration Low Side
• Rds-On-Typ 120 mOhm (Max)
• Voltage-Load 36V (Max)
• Current-Output-Max 3.5A
• Switch-Type General Purpose
• Pd-Power-Dissipation 35 W
• Maximum-Operating-Temperature + 150 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Current 100 uA
• Output-Current 3.5 A
• Fall-Time 250 ns
• Rise-Time 250 ns
• Supply-Voltage-Max 55 V
• Supply-Voltage-Min 2.5 V
• Number-of-Drivers 1 Driver
• Maximum-Turn-Off-Delay-Time 450 ns (Typ)
• Maximum-Turn-On-Delay-Time 90 ns (Typ)
